Attach the grommet end of the ground wire to the piece of bare metal using the provided self-tapping screw and a screwdriver. Locate a section of bare metal within the vehicle close to the VBX12A. 7 Attach the brown ground wire from the amplifier wiring kit to the Visonik VBX12A using a screwdriver. Plug the patch cables into the RCA inputs on the VBX12A. Route the patch cables to the Visonik VBX12A.
Route the blue wire to the Visonik VBX12A and secure the accessory wire to the device using a screwdriver.Ħ Plug the RCA patch cables from the amplifier wiring kit into the RCA pre-outs on the back of the vehicle's stereo. Wrap the bare wire end of the corresponding wire from the amplifier wiring kit around the bare section of the accessory wire and wrap the connection in electrical tape. 5 Locate the blue accessory wire connected to the stereo and remove 1/4-inch of the its plastic protective coating using a Klein tool. Secure the power wire using a screwdriver. Route the power wire through an existing hole in the vehicle's firewall to the Visonik VBX12A. 4 Attach the red power wire with in-line fuse from an amplifier wiring kit to the vehicle's positive battery terminal by slipping the grommet end over the terminal and securing with the provided nut and a crescent wrench. Expose the stereo wires by sliding the stereo forward.ģ Secure the Visonik VBX12A in place using the provided hardware and following the manufacturer's instructions. Remove the screws that secure the stereo in place using a screwdriver. 2 Remove the plastic bezel that surrounds the stereo using a panel removal tool. Skill level:Moderate Things you need Crescent wrenchPanel toolScrewdriverAmplifier wiring kitKlein toolElectrical tape Instructions 1 Locate the vehicle's battery and disconnect the black negative cable using a crescent wrench. The Visonik VBX12A features RCA inputs which help to simplify the installation when used with an amplifier wiring kit.
The built-in amplifier, stable down to four ohms, is capable of producing 225 watts of constant power. Consisting of a subwoofer enclosure, subwoofer and amplifier, the Visonik VBX12A is an all-in-one aftermarket solution for reproducing low-end frequencies produced by your vehicle's stereo receiver.
